Prodcut Name:62200、62300 Series

Code: 1368941524 Price:0

62200
Bearing					KN)		Ball Complement				KG
No .	Bore	O.D.	Width	Chamfer	Load Rating				Maxrunout speed
	d	D	B	r/min
	mm	mm	mm	mm	Dynamic	Static	No.	Size	Grease	Oil	KG
					Cr	Co	No.	mm	r/min	r/min	KG
62200	10	30	14	0.6	3.928	2.23	8	4.762	19000	26000	0.044
62201	12	32	14	0.6	5.241	3.02	7	5.953	18000	24000	0.0531
62202	15	35	14	0.6	5.864	3.49	8	5.953	17000	22000	0.065
62203	17	40	16	0.6	7.36	4.48	8	6.747	16000	20000	0.096
62204	20	47	18	1.1	9.867	6.2	8	7.938	14000	18000	0.15
62205	25	52	18	1	10.78	6.98	9	7.938	13000	16000	0.178
62206	30	62	20	1	14.9	10	9	9.525	12000	13000	0.215
62207	35	72	23	1.1	21.6	13.7	9	11.112	95000	11000	0.31
62208	40	80	23	1.1	22.8	15.8	9	12	8500	10000	0.406
62209	45	85	23	1.1	24.5	17.5	10	12	7000	9000	0.455
62210	50	90	23	1.1	27	19.8	10	12.7	6700	9000	0.496


62300

			Width		(KN)				Maxrunout speed
Bearing	Bore	O.D.	B	Chamfer	Load Rating		Ball Complement
No .	d	D	mm	r/min
	mm	mm		mm	Dynamic	Static	No.	Size	Grease	Oil
					Cr	Co	No.	mm	r/min	r/min
62300	10	35	17	0.6	5.88	3.47	7	6.35	18000	24000
62301	12	37	17	1	7.48	4.65	6	7.938	17000	22000
62302	15	42	17	1	8.791	5.42	7	7.938	16000	20000
62303	17	47	19	1	10.438	6.58	7	8.731	15000	19000
62204	20	52	21	1.1	12.26	7.81	7	9.525	14000	18000
62305	25	62	24	1.1	17.22	11.39	7	11.5	12000	16000
62206	30	72	27	1.1	20.77	14.7	8	12	10000	14000
62307	35	80	31	1.5	25.66	17.92	8	13.494	9000	13000
62308	40	90	33	1.5	36.2	23.5	8	15.081	7000	9000
62309	45	100	36	1.5	47.7	29.9	8	17.462	6300	8000
62310	50	110	40	2	Pre:16000 Series Next:Miniature bearings Home About Us Products Feedback Contact Us Sitemap Online Service
